HYDRAULIC PRESSURE GAUGE 0-315 BAR VERTICAL CONNECTION

Name: HYDRAULIC PRESSURE GAUGE 0-315 BAR VERTICAL CONNECTION
Brand: DICSA
SKU: HK_MFI6304315V
Price: 19 EUR
Availability: InStock

Connection: 1/4" BSP

Connection point: Vertical

Measuring range: 0-315 bar

Operating temperature: -20°C / +60°C

Manufacturer: DICSA

Datasheet: Click here to download

In stock

15 €+VAT

Item number:

HK_MFI6304315V

Glycerine filled pressure gauge DN 63, 1/4" BSP, bottom connection, 0–315 bar

Product description:

This is a DN 63 diameter, bottom (vertical) connection, glycerine-filled pressure gauge with 1/4" BSP threaded connection. The glycerine filling dampens vibrations and pressure spikes, providing more stable and accurate readability in hydraulic systems and industrial applications. The instrument features a dual bar/psi scale and IP65 protection rating, ensuring reliable operation even in dusty or wet environments.

Technical data:

Connection: 1/4" BSP
Design: bottom connection, glycerine filled
Measuring range: 0–315 bar
Accuracy class: 1.6%
Case material: stainless steel 304
Bezel material: stainless steel 304
Window: polycarbonate
Connection/thread material: brass
Protection rating: IP65
Operating temperature: -20 °C – +60 °C

Data

Weight:

200 g/pc(s)

Details

Operating Principle

Inside the gauge, a Bourdon tube flexes in response to internal pressure, straightening slightly as the pressure increases. This movement is transferred through a linkage mechanism to the pointer, which indicates the pressure on the dial. The system is fully mechanical, requiring no electricity or external power, making it a simple yet highly reliable tool for industrial pressure monitoring.
