Operating Principle

The VP1‑130‑L is a fixed displacement axial piston pump that works on the principle of axial piston movement within a swashplate design. Multiple pistons are arranged in a circular pattern and move axially back and forth as the shaft rotates. This motion creates alternating suction and pressure phases, allowing hydraulic fluid to be drawn in and pushed out at a consistent volume. Because the displacement is fixed, the pump delivers a steady and predictable flow per revolution. The design ensures high efficiency, smooth operation, and reliable performance under demanding working conditions.

PARKER PISTON HYDRAULIC PUMP VP1-130-L

Article No.:
P_3784501
Available for order
3 669+VAT

The Parker VP1-130-L is a high-performance, fixed displacement axial piston pump designed specifically for demanding mobile hydraulic applications, particularly in transport and construction vehicles.

It delivers up to 400 bar of intermittent pressure and features a robust design that ensures long-lasting operation under heavy load conditions. With a displacement of 128 cm³/rev and maximum speed of 3000 rpm, this pump is ideal for systems requiring consistent high flow and pressure. Its compact build and compatibility with ISO 7653-1985 mounting flanges and DIN 5462 shafts make installation easy in most truck PTO configurations.

Trusted by industrial and logistics companies alike, the VP1 series combines efficiency, reliability, and power in one compact unit.



Delivery time: The product is currently in an external warehouse, so it may reach you within 4-8 business days.
Delivery capacity (cm³/rev; liters/min): 128
Max. pressure (bar): 400
Design: AXIAL PISTON HYDRAULIC PUMP
Variable / Fixed displacement: Variable displacement hydraulic pump
Direction of rotation: Left
Manufacturer: PARKER
Manufacturer part number: 3784501
