P70CF-05-050967-01 EP + By pass HIDRAULIKUS SZELEP - Seres 2 karos konténeres felépítményhez

Article No.:
P_2210045301
P70CF-05-050967-01 EP + By pass HIDRAULIKUS SZELEP - Seres 2 karos konténeres felépítményhez
Manufacturer: TRALE
2 713+VAT

The Seres P70CF-05-050967-01-EP is a manually operated, single-lever hydraulic control valve featuring an integrated by-pass function. Designed for use in trailers, machinery, and industrial equipment, it provides reliable and efficient control over a single hydraulic actuator.

The 3/8” BSP ports and robust construction make it suitable for demanding work environments. The built-in by-pass allows oil to flow freely in neutral position, reducing energy use and protecting the pump during idle periods.



Details

Operating principle

Internally, the valve contains a spool mechanism controlled by the lever. Pushing the lever forward or backward opens the respective pressure or return ports, directing oil flow to the corresponding side of the actuator.

In the neutral (center) position, the integrated by-pass channels allow fluid to circulate freely back to the tank or downstream, minimizing pressure buildup. This feature is ideal for multi-user systems or when efficient pump unloading is essential.

P70CF-05-050967-01 EP + By pass HIDRAULIKUS SZELEP - Seres 2 karos konténeres felépítményhez
P70CF-05-050967-01 EP + By pass HIDRAULIKUS SZELEP - Seres 2 karos konténeres felépítményhez
2 713+VAT
