Hydraulic Monoblock Valve YFM55/5 1/2 5P DDDDD
Product description:
The YFM55/5 1/2 5P DDDDD is a five-section, high-performance, manually operated hydraulic directional control valve that provides DE (double effect) – double-acting – control on all five working circuits. Each spool is equipped with a spring return mechanism, ensuring a high level of operational safety and precise, reliable control.
The YFM55 valve series is designed for heavy-duty applications and can handle up to 60 l/min maximum flow rate with a maximum operating pressure of 315 bar. The integrated pressure relief valve is factory-set to 120 bar and is adjustable within a 63–200 bar range. The 1/2" BSP ports ensure compatibility with a wide range of industrial and mobile hydraulic systems.
Technical specifications:
- Maximum flow rate: 60 l/min
- Maximum operating pressure: 315 bar
- Max. tank line pressure (T port): 25 bar
- Relief valve range: 63–200 bar (factory: 120 bar)
- Number of sections: 5
- Spool type: DDDDD – five double-acting circuits
- Connections: 1/2" BSP (A, B, P, T ports)
Applications:
- Simultaneous control of five double-acting hydraulic cylinders
- High-performance lifting, loading and manipulator equipment
- Industrial and agricultural multi-circuit hydraulic systems
- Complex hydraulic control of medium and large mobile machinery
The YFM55/5 1/2 5P DDDDD valve is an excellent solution for applications requiring precise, efficient and long-lasting control of multiple high-load hydraulic circuits within a compact and robust valve assembly.
