Hydraulic Monoblock Valve YFM35/5 3/8 5P DDDDD
Product description:
The YFM35/5 3/8 5P DDDDD is a five-section, manually operated hydraulic directional control valve that provides DE (double effect) – double-acting – control on all five working circuits. Each spool features a spring return mechanism, ensuring that the hydraulic circuits return to a safe neutral position immediately when the operator releases the lever.
The YFM35 series is a high-performance compact valve family capable of handling a 45 l/min maximum flow rate and a 315 bar maximum operating pressure. The built-in pressure relief valve is factory-set to 140 bar, adjustable within a 60–200 bar range. The 3/8" BSP connections ensure compatibility with most mobile hydraulic applications.
Technical specifications:
- Maximum flow rate: 45 l/min
- Maximum operating pressure: 315 bar
- Max. tank line pressure (T port): 25 bar
- Relief valve range: 60–200 bar (factory: 140 bar)
- Number of sections: 5
- Spool type: DDDDD – five double-acting circuits
- Connections: 3/8" BSP (A, B, P, T ports)
Applications:
- Multi-circuit hydraulic systems
- Simultaneous control of five double-acting cylinders
- Lifting, loading and handling equipment
- Compact hydraulic machinery and industrial applications
The YFM35/5 3/8 5P DDDDD valve is an excellent solution for systems requiring precise, stable and safe control of a large number of double-acting hydraulic circuits within a compact, robust valve block.
