HYDRAULIC 2 WAYS BALL VALVE 12S OUTER THREAD

Name: HYDRAULIC 2 WAYS BALL VALVE 12S OUTER THREAD
Brand: GEMELS
SKU: HK_GE2DDS25011A000
Price: 32 EUR
Availability: InStock

Type of valve: System integrable valve

Type of block: Ball valve

Max. pressure: 500 bar

Connection: M20X1,5

Max. flow rate: N/A

Pipe / Hose connection: Metric

Pipe / Hose connection size: DN 8

Thread location: OUTER

Seal: NBR: +100°C / -20°C

Manufacturer: GEMELS

Datasheet: Kattintson ide a letöltéshez

In stock

25 €+VAT

Item number:

HK_GE2DDS25011A000

GE2 12S DIN 2353 S – 2-way ball valve

Product description:

The GE2 12S 2-way ball valve is designed for hydraulic systems with DIN 2353 S (Heavy Series) connections, providing safe and reliable opening and shut-off of hydraulic flow. It features a carbon steel housing and is engineered for high-pressure applications, ensuring dependable operation in truck hydraulic systems and industrial use.

Key features:

Type: 2-way ball valve
Part number: GE2DDS25011A000
Connection: DIN 2353 S (Heavy Series)
Nominal diameter (DN): 12
Maximum operating pressure: 500 bar
Housing material: Carbon steel
Weight: 0.599 kg

Data

Weight:

400 g/pc(s)

Details

Operating Principle

Inside the valve, a perforated steel ball rotates 90° using the handle to open or close the oil flow. When the bore aligns with the pipeline direction, fluid flows through freely; when turned, the solid side of the ball blocks the passage completely.

This mechanical shut-off ensures fast and secure operation for isolating or controlling hydraulic flow. The valve is perfectly suited for applications like hydraulic cylinders or circuit isolation.

HYDRAULIC 2 WAYS BALL VALVE 12S OUTER THREAD

25 €+VAT
