SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32
SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32 SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32
Details

The Sunfab SLPD 64/32 DIN series twin pumps are exceptionally low-noise and specifically designed for demanding mobile hydraulic systems. The SLPD 64/32 DIN is available in eight different sizes, with three models offering differentiated flow capacities. These pumps with varying flow capacities expand the range of applications, as they can provide three different flow rates: one small, one large, and one combined capacity.

The maximum pressure varies between 330–350 bar, depending on the model. Its slim pump housing allows for direct mounting on the power take-off (PTO), even directly beside the vehicle's drive shaft in very confined spaces. The SLPD 64/32 DIN can also be installed using a mounting bracket and driven via an intermediate shaft (cardan). Versions equipped with a Savtec bypass valve are suitable for applications where hydraulics need to be operated while the vehicle is in motion.

SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32

Article No.:
HK_18656
Available for order
1 681+VAT

The SUNFAB SLPD 64/32 is a high-performance dual-flow axial piston pump designed for demanding mobile and industrial hydraulic systems. With two displacement volumes of 63.0 cm³/rev and 31.5 cm³/rev, it can simultaneously supply two separate hydraulic circuits, such as operating cranes, lifts, and tipping systems concurrently. Its compact design and low noise level make it ideal for installation in trucks and machinery.

The robust construction and SUNFAB's premium quality ensure long service life and reliable operation even under extreme working conditions. This model features an independent direction of rotation, so it's important to confirm the drive side before installation.



Delivery time: The product is currently in an external warehouse, so it may reach you within 4-8 business days.
Delivery capacity (cm³/rev; liters/min): 64/32
Max. pressure (bar): 350
Design: AXIAL PISTON HYDRAULIC PUMP
Variable / Fixed displacement: Constant volume displacement hydraulic pump
Direction of rotation: Neutral
Manufacturer: SUNFAB
Manufacturer part number: 18656
Info
Weight:
26 kg/pc(s)
SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32
SUNFAB PISTON HYDRAULIC PUMP SLPD-64/32
1 681+VAT
