OMFB HYDRAULIC GEAR PUMP NPLU 20SX Z=13

Article No.:
HK_10500320206
OMFB HYDRAULIC GEAR PUMP NPLU 20SX Z=13
OMFB HYDRAULIC GEAR PUMP NPLU 20SX Z=13 OMFB HYDRAULIC GEAR PUMP NPLU 20SX Z=13
Delivery time: The product is currently in an external warehouse, so it may reach you within 4-8 business days.
Delivery capacity (cm³/rev; liters/min): 20
Max. pressure (bar): 260
Design: Gear pump
Variable / Fixed displacement: Constant volume displacement hydraulic pump
Direction of rotation: Left
Manufacturer: OMFB
Manufacturer part number: 10500320206
Available for order
274+VAT

The OMFB NPLU-20SX Z13 is a unidirectional gear hydraulic pump designed for medium-duty applications. With a displacement of 20.12 cm³ per revolution, it delivers consistent hydraulic power suitable for various industrial and agricultural machinery. Constructed with a durable cast-iron housing and a bronze thrust plate, this pump ensures longevity and reliable performance.

It features a left-hand (anti-clockwise) rotation, a 13-tooth DIN 5482 spline shaft (22x19 mm), and G 3/4" inlet and G 1/2" outlet ports, facilitating easy integration into existing hydraulic systems. The NPLU-20SX Z13 supports a maximum continuous operating pressure of 260 bar, making it a dependable choice for systems requiring steady flow and pressure.



Info
Weight:
7 kg/pc(s)
