Thermal switch ILLZTH9069K
Product description:
The ILLZTH9069K is an ASA Hydraulik bimetallic thermal switch with a switching temperature of 90°C and IP 69K protection rating, which — when paired with the ILLZTC12-2K (12V DC) or ILLZTC24-2K (24V DC) temperature control unit — enables speed-proportional fan control. On its own, it operates in simple on/off mode based on the switching temperature — but when combined with a control unit, it drives the fan on a soft-start curve, which significantly reduces thermal stress on components and extends the fan's service life. It can be installed on all ASA coolers and BSP 1/2" connections.
Key features:
- Order number: ILLZTH9069K
- Manufacturer: ASA Hydraulik
- Switching temperature: 90°C
- Temperature differential: ±5°C
- Protection class: IP 69K
- Connection thread: BSP 1/2"
- Electrical connector: AMP Superseal 1.5
- Max. current: 12V DC: 10(1)A / 24V DC: 10(1)A / 125V AC: 10(1)A / 250V AC: 10(1)A
- Switching cycles: 100,000
- Screw material: brass
- Mounting: any position
- Max. tightening torque: 40 Nm
- Weight: 0.10 kg
- Operating temperature: -20°C – +100°C
- Storage temperature: -40°C – +110°C
- Compatible controllers: ILLZTC12-2K (12V DC), ILLZTC24-2K (24V DC)
